EH100
SMAX
90106000
Electric Screens are perfect for any classroom or office. Electric projection screen is one of the most technically advance screens today, with motor device, you can control the screen using In-line Switch or remote controller, the screen can be stop at any position. Perfectly flat screen fabric surface ensure images are perfect. The screen is widely used in hotels, business centers, meeting rooms, schools, small cinemas, entertainment centers etc.
Features of Electric Screen
* High quality spraying painting metal casing is shaped by punch machine, strong and elegant, white or black color is available
* Use the best quality screen fabric to ensure perfect flat surface
* Equipped synchronous motor ,low noise and cost but stable quality, tubular motor is optional. The biggest screen size for synchronous motor is 150”.
* Ease of installation, wall or ceiling mounted are available
* Standard with In-line Switch, Remote controller is optional to control the screen friendly
Main applications
Education、Business presentations、Hotel、Cinema、Entertainment venues etc
Fabrics are available on our Electric Screen
* Fiberglass Matte
* Quality Matte White
* Matte White
* Matte Grey
Electric Screens are perfect for any classroom or office. Electric projection screen is one of the most technically advance screens today, with motor device, you can control the screen using In-line Switch or remote controller, the screen can be stop at any position. Perfectly flat screen fabric surface ensure images are perfect. The screen is widely used in hotels, business centers, meeting rooms, schools, small cinemas, entertainment centers etc.
Features of Electric Screen
* High quality spraying painting metal casing is shaped by punch machine, strong and elegant, white or black color is available
* Use the best quality screen fabric to ensure perfect flat surface
* Equipped synchronous motor ,low noise and cost but stable quality, tubular motor is optional. The biggest screen size for synchronous motor is 150”.
* Ease of installation, wall or ceiling mounted are available
* Standard with In-line Switch, Remote controller is optional to control the screen friendly
Main applications
Education、Business presentations、Hotel、Cinema、Entertainment venues etc
Fabrics are available on our Electric Screen
* Fiberglass Matte
* Quality Matte White
* Matte White
* Matte Grey
Model No. | Size | Format | View Area( W x H) | Housing Size | Packing Size | Gross Weight |
Inch | Unit: mm | Unit: mm | Unit: mm | Unit: Kgs | ||
ES60 | 60"x60" | 1:1 | 1520 x 1520 | 1780x94x80 | 1870×150×135 | 9.5 |
ES70 | 70"x70" | 1800 x 1800 | 2030x94x80 | 2120×150×135 | 10.8 | |
ES80 | 80"x80" | 2030 x 2030 | 2290x94x80 | 2400×150×135 | 12 | |
ES84 | 84"x84" | 2130 x 2130 | 2330x94x80 | 2480×150×135 | 12.8 | |
ES96 | 96"x96" | 2440 x 2440 | 2640x94x80 | 2800×150×135 | 14.8 | |
EV72 | 72" | 4:3 | 1460 x 1100 | 1720x94x80 | 1810×150×135 | 8.5 |
EV84 | 84" | 1710 x 1280 | 1960x94x80 | 2050×150×135 | 9.5 | |
EV92 | 92" | 1860 x 1400 | 2140x94x80 | 2230×150×135 | 10.4 | |
EV100 | 100" | 2030 x 1520 | 2310x94x80 | 2400×150×135 | 11.5 | |
EV120 | 120" | 2440 x 1830 | 2710x94x80 | 2800×150×135 | 13.7 | |
EV150 | 150" | 3050 x 2290 | 3310x94x80 | 3400×150×135 | 16.5 | |
EH84 | 84" | 16:9 | 1860 x 1040 | 2120x94x80 | 2230×150×135 | 10.6 |
EH92 | 92" | 2030 x 1150 | 2290x94x80 | 2380×150×135 | 11.4 | |
EH100 | 100" | 2210 x 1240 | 2490x94x80 | 2580×150×135 | 11.9 | |
EH106 | 106" | 2350 x 1320 | 2630x94x80 | 2740×150×135 | 12.3 | |
EH120 | 120" | 2650 x 1490 | 2930x94x80 | 3020×150×135 | 14.7 | |
EH150 | 150" | 3310 x 1860 | 3650x94x80 | 3730×150×135 | 17.5 | |
EW86 | 86" | 2.35:1 | 2000 x 850 | 2260x94x80 | 2350×150×135 | 10 |
EW98 | 98" | 2300 x 980 | 2580x94x80 | 2670×150×135 | 11 | |
EW113 | 113" | 2650 x 1130 | 2930x94x80 | 3020×150×135 | 13 | |
EW128 | 128" | 3000 x 1280 | 3320x94x80 | 3400×150×135 | 14 | |
EW140 | 140" | 3300 x 1400 | 3620x94x80 | 3730×150×135 | 15 |
Model No. | Size | Format | View Area( W x H) | Housing Size | Packing Size | Gross Weight |
Inch | Unit: mm | Unit: mm | Unit: mm | Unit: Kgs | ||
ES60 | 60"x60" | 1:1 | 1520 x 1520 | 1780x94x80 | 1870×150×135 | 9.5 |
ES70 | 70"x70" | 1800 x 1800 | 2030x94x80 | 2120×150×135 | 10.8 | |
ES80 | 80"x80" | 2030 x 2030 | 2290x94x80 | 2400×150×135 | 12 | |
ES84 | 84"x84" | 2130 x 2130 | 2330x94x80 | 2480×150×135 | 12.8 | |
ES96 | 96"x96" | 2440 x 2440 | 2640x94x80 | 2800×150×135 | 14.8 | |
EV72 | 72" | 4:3 | 1460 x 1100 | 1720x94x80 | 1810×150×135 | 8.5 |
EV84 | 84" | 1710 x 1280 | 1960x94x80 | 2050×150×135 | 9.5 | |
EV92 | 92" | 1860 x 1400 | 2140x94x80 | 2230×150×135 | 10.4 | |
EV100 | 100" | 2030 x 1520 | 2310x94x80 | 2400×150×135 | 11.5 | |
EV120 | 120" | 2440 x 1830 | 2710x94x80 | 2800×150×135 | 13.7 | |
EV150 | 150" | 3050 x 2290 | 3310x94x80 | 3400×150×135 | 16.5 | |
EH84 | 84" | 16:9 | 1860 x 1040 | 2120x94x80 | 2230×150×135 | 10.6 |
EH92 | 92" | 2030 x 1150 | 2290x94x80 | 2380×150×135 | 11.4 | |
EH100 | 100" | 2210 x 1240 | 2490x94x80 | 2580×150×135 | 11.9 | |
EH106 | 106" | 2350 x 1320 | 2630x94x80 | 2740×150×135 | 12.3 | |
EH120 | 120" | 2650 x 1490 | 2930x94x80 | 3020×150×135 | 14.7 | |
EH150 | 150" | 3310 x 1860 | 3650x94x80 | 3730×150×135 | 17.5 | |
EW86 | 86" | 2.35:1 | 2000 x 850 | 2260x94x80 | 2350×150×135 | 10 |
EW98 | 98" | 2300 x 980 | 2580x94x80 | 2670×150×135 | 11 | |
EW113 | 113" | 2650 x 1130 | 2930x94x80 | 3020×150×135 | 13 | |
EW128 | 128" | 3000 x 1280 | 3320x94x80 | 3400×150×135 | 14 | |
EW140 | 140" | 3300 x 1400 | 3620x94x80 | 3730×150×135 | 15 |
